Technology
|
Projection System
|
3LCD Technology
|
LCD Panel
|
0.59 inch with C2 Fine
|
|
Color Light Output
|
2,200 Lumen- 1,100 Lumen(economy) In accordance with IDMS15.4
|
White Light Output
|
2,200 Lumen - 1,100 Lumen(economy) In accordance with ISO 21118:2020
|
Resolution
|
WXGA 2
|
Aspect Ratio
|
16:10
|
Contrast Ratio
|
5,000,000: 1
|
Native Contrast
|
2,000: 1
|
Light source
|
Laser
|
Laser Light source
|
20,000 hoursDurability High, 30,000 hoursDurability Eco
|
Keystone Correction
|
Manual vertical: ±45 °, Manual horizontal ±40 °
|
Colour Reproduction
|
16.77 million colours
|
Optical
|
Throw Ratio
|
1.38 - 2.19:1
|
Zoom
|
Motorized, Factor:1 - 1.58
|
Lens
|
Optical
|
Screen Size
|
30 inches - 150 inches
|
Projection Distance Wide
|
0.9 m - 4.5 m
|
Projection Lens F Number
|
1.51 - 1.92
|
Projection Lens Focal Length
|
18.2 mm - 28.4 mm
|
Projection Lens Focus
|
Motorized
|
Connectivity
|
Interfaces
|
USB 2.0-A, USB 2.0 Type B (Service Only), Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN b/g/g 25GHz, HDMI in, Jack plug out, SD Card Slot, SD Card playback, Wireless LAN a/n (5GHz)
|
Network Protocol
|
HTTPS, IPv6, SNMP, ESC/VP.net, PJLink
|
Advanced Features
|
Security
|
Wireless LAN security, Password protection
|
Other features
|
A/V mute, Auto Power On, Digital zoom, Edge Blending, Horizontal and vertical keystone correction, Image Shift, Long light source life, Quick Corner, Web Control, Web Remote
|
Video Color Modes
|
Dynamic, Normal
|
Projector control
|
via: Crestron, Crestron Integrated Partner, Crestron RoomView
|
General
|
Power consumption
|
124 Watt (Normal On-Mode), 149 Watt (Normal Peak-mode), 112 Watt (Eco Peak-Mode), 0.4 Watt (Energy saving standby)
|
Supply Voltage
|
AC 100 V - 240 V, 50 Hz - 60 Hz
|
Product weight
|
5 kg
|
Noise Level
|
Normal:34 dB (A) - Economy:22 dB (A)
|
Supported Temperature
|
Operation 5° C - 40° C, Storage -10° C - 60° C
|
Supported Humidity
|
Operation 20% - 80%, Storage 10% - 90%
|
Included Software
|
Epson Creative Projection, Epson Projector Content Manager
|
Options
|
External Speaker, Floor stand, Lighting track mount
|
What's in the box
|
Cable cover, Direct mount unit, HDMI Cable Clamp, Hexagon wrench, Installation/safety manual, Power cable, Quick Start Guide, Remote control incl. batteries, Safety wire set, User Manual (CD-ROM)
|
Room Type / Application
|
Projection Mapping, Signage / Retail, Visitor Attraction
|
Positioning
|
Ceiling Mounted, Floor, Lighting Track, Wall Mounted
|
Colour
|
White
|
Other
|
Warranty
|
60 months Carry in or 12,000 h
|
