Technology
|
Projection System
|
3LCD Technology
|
LCD Panel
|
0.67 inch with C2 Fine
|
|
Color Light Output
|
7,000 Lumen- 4,900 Lumen(economy) In accordance with IDMS15.4
|
White Light Output
|
7,000 Lumen In accordance with ISO 21118:2020
|
Resolution
|
WUXGA
|
Resolution Enhancement
|
4K enhancement
|
Aspect Ratio
|
16:10
|
On-Screen Pixel Count
|
4,608,000 (1920 x1200 x2)
|
Contrast Ratio
|
Over 5,000,000: 1
|
Light source
|
Laser
|
Laser Light source
|
20,000 hoursDurability High, 30,000 hoursDurability Eco
|
Keystone Correction
|
Manual vertical: ±30 °, Manual horizontal ±30 °
|
Colour Video Processing
|
10 Bits
|
Colour Reproduction
|
Upto 1.07 billion colours
|
HDR support
|
HDR10
|
Optical
|
Throw Ratio
|
1.35 - 2.20:1
|
Zoom
|
Manual, Factor:1 - 1.6
|
Lens
|
Optical
|
Lens Shift
|
Manual - Vertical ±50 %, horizontal ±20 %
|
Screen Size
|
50 inches - 500 inches
|
Projection Lens F Number
|
1.5 - 1.7
|
Projection Lens Focal Length
|
20 mm - 31.8 mm
|
Projection Lens Focus
|
Manual
|
Connectivity
|
Interfaces
|
USB 2.0-A, USB 2.0 Type B (Service Only), RS-232C, HDMI in (2x), HDMI out, HDBaseT, Jack plug out, Ethernet interface (100 Base-TX / 10 Base-T)
|
Epson iProjection App
|
Ad-Hoc / Infrastructure
|
Network Protocol
|
HTTPS, IPv6, SNMP, PJLink
|
Advanced Features
|
Security
|
Kensington lock, Password lock, Security cable hole, Wireless LAN unit lock, Password protection
|
2D Colour Modes
|
Dynamic, Natural, Cinema, Presentation, DICOM SIM
|
Other features
|
21:9 aspect ratio support, 4K enhancement, A/V mute, Arc Correction, Auto source search, Built-in speaker, CEC compatible, Direct Power on/off, Document Camera Compatible, Edge Blending, PC Free, Super resolution, Ultra-wide display (16:6), iProjection App
|
Video Color Modes
|
Cinema, Dynamic, Natural, Presentation, DICOM SIM, Multi Projection, BT709
|
Projector control
|
via: Crestron, Crestron Integrated Partner, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol
|
General
|
Power consumption
|
300 Watt (Normal On-Mode), 209 Watt (Eco On-Mode), 366 Watt (Normal Peak-mode), 277 Watt (Eco Peak-Mode), 0.5 Watt (Energy saving standby)
|
Supply Voltage
|
AC 100 V - 240 V, 50 Hz - 60 Hz
|
Product dimensions
|
440 x 304 x 122 mm (Width x Depth x Height)
|
Product weight
|
8.5 kg
|
Noise Level
|
Normal:38 dB (A) - Economy:27 dB (A)
|
Supported Temperature
|
Storage -10° C - 60° C
|
Supported Humidity
|
Operation 20% - 80%, Storage 10% - 90%
|
Included Software
|
Epson Projector Management
|
Options
|
Air filter, Ceiling mount, Connection and control box, Document camera, External Speaker, Safety wire set, Visualiser camera, WP System - ELPWP20
|
Loudspeaker
|
10 Watt
|
What's in the box
|
Cable cover, HDMI Cable, Main unit, Power cable, Remote control incl. batteries, User guide, Warranty document
|
Room Type / Application
|
Boardroom, Large Meeting Room / Auditorium, Meeting room / Classroom, Projection Mapping, Signage / Retail, Visitor Attraction
|
Positioning
|
Ceiling Mounted, Desktop
|
Colour
|
Black
|
TCO Certified
|
For further information relating to TCO Certified please visit https://tcocertified.com/files/certification/Information-document-for-end-users.pdf
|
Other
|
Warranty
|
36 months Carry in
|
Country of Origin
|
Country Of Origin
|
Philippines
|
