Technology
|
Projection System
|
3LCD Technology, RGB liquid crystal shutter
|
LCD Panel
|
0.67 inch with C2 Fine
|
|
Color Light Output
|
7,000 Lumen- 4,900 Lumen(economy) In accordance with IDMS15.4
|
White Light Output
|
7,000 Lumen - 4,900 Lumen(economy) In accordance with ISO 21118:2020
|
Resolution
|
WUXGA
|
Resolution Enhancement
|
Full HD
|
Aspect Ratio
|
16:10
|
On-Screen Pixel Count
|
2,304,000
|
Contrast Ratio
|
5,000,000: 1
|
Light source
|
Laser
|
Laser Light source
|
20,000 hoursDurability High, 30,000 hoursDurability Eco
|
Keystone Correction
|
Manual vertical: ±30 °, Manual horizontal ±30 °
|
Colour Video Processing
|
10 Bits
|
2D Vertical Refresh Rate
|
192 Hz - 240 Hz
|
Colour Reproduction
|
Upto 1.07 billion colours
|
Optical
|
Throw Ratio
|
1.35 - 2.20:1
|
Zoom
|
Manual, Factor:1 - 1.6
|
Lens
|
Optical
|
Screen Size
|
50 inches - 500 inches
|
Projection Lens F Number
|
1.5 - 1.7
|
Projection Lens Focal Length
|
20 mm - 31.8 mm
|
Projection Lens Focus
|
Manual
|
Offset
|
27: 1
|
Connectivity
|
Interfaces
|
RS-232C, Ethernet Interface (1000 Base-T/ 100-Base TX/ 10-Base-T), VGA in (2x), VGA out, HDMI in (2x), HDBaseT, Miracast (optional), Jack plug out, Jack plug in (2x), USB 2.0-A, USB 2.0, Wireless LAN IEEE 802.11a/b/g/n/ac (optional)
|
Epson iProjection App
|
Ad-Hoc / Infrastructure
|
Advanced Features
|
Security
|
Kensington lock, Padlock, Security cable hole, Wireless LAN unit lock
|
2D Colour Modes
|
Dynamic, Cinema, Presentation, sRGB, DICOM SIM
|
Other features
|
21:9 aspect ratio support, A/V mute, Arc Correction, Auto source search, Built-in speaker, CEC compatible, Edge Blending, Home Screen, Instant on/off, Long light source life, PC Free, Power on button, Screen share, Split-Screen-Function, Ultra-wide display (16:6), iProjection App
|
Video Color Modes
|
Cinema, Dynamic, Presentation, sRGB, DICOM SIM
|
Projector control
|
via: AMX, Crestron, Control4, Crestron Integrated Partner, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol
|
General
|
Power consumption
|
287 Watt (Normal On-Mode), 187 Watt (Eco On-Mode), 345 Watt (Normal Peak-mode), 258 Watt (Eco Peak-Mode), 0.3 Watt (Energy saving standby)
|
Supply Voltage
|
AC 100 V - 240 V, 50 Hz - 60 Hz
|
Product dimensions
|
440 x 122 x 304 mm (Width x Depth x Height)
|
Product weight
|
7.8 kg
|
Noise Level
|
Normal:39 dB (A) - Economy:27 dB (A)
|
Supported Temperature
|
Storage -10° C - 60° C
|
Supported Humidity
|
Operation 20% - 80%, Storage 10% - 90%
|
Included Software
|
EasyMP Multi PC Projection
|
Options
|
Air filter, Ceiling mount, Document camera, External Speaker, HDBaseT Transmitter, Safety wire set, Suspension adapter, WP System - ELPWP10, Wireless LAN unit, Wireless transmitter - ELPWT01
|
Loudspeaker
|
10 Watt
|
What's in the box
|
HDMI Cable, Main unit, Power cable, Remote control incl. batteries, User guide, Warranty Documents
|
Room Type / Application
|
Boardroom, Home Office, Large Meeting Room / Auditorium, Meeting room / Classroom, Signage / Retail, Visitor Attraction
|
Positioning
|
Ceiling Mounted, Desktop, Floor, Wall Mounted
|
Colour
|
White
|
TCO Certified
|
For further information relating to TCO Certified please visit https://tcocertified.com/files/certification/Information-document-for-end-users.pdf
|
Other
|
Warranty
|
36 months Carry in
|
Country of Origin
|
Country Of Origin
|
Philippines
|
